Peerless 850 571 Mid Woofer 4″ Hi – Fi CSC LINE (Pair)

17%
Peerless 850 571 Mid Woofer 4" Hi - Fi CSC LINE (Pair)
All products by PEERLESS

Original price was: €135.00.Current price is: €111.37. incl. GR VAT

Available on backorder

EAN: N/A
Installments calculation €
CompareAdd to wishlist Submit Better Price

    Availability: Upon Request Upon Request SKU: 850571 Category: Brand:
    Specifications Power (RMS): 110 Watt Impadence : 4 Ohm Megaphone Depth: 57mm Hole Diameter : 100 mm Sensitivity : 90 db Size : 4 Inches



    Read more

    Specifications
    Power (RMS):
    110 Watt

    Impadence :
    4 Ohm

    Megaphone Depth:
    57mm
    Hole Diameter :
    100 mm

    Sensitivity :
    90 db

    Size :
    4 Inches

    Weight 0.40 kg
    Speaker Inch

    Reviews

    There are no reviews yet.

    Be the first to review “Peerless 850 571 Mid Woofer 4″ Hi – Fi CSC LINE (Pair)”

    Your email address will not be published. Required fields are marked *

    Quick Comparison

    Peerless 850 571 Mid Woofer 4" Hi - Fi CSC LINE (Pair) removeJBL 2106H 339485-001X Midrange Driver 2106HPL removeBMS BMS5C150H 5 C 150 H - 5" Ferrit Coaxial Speaker 130 W + 25 W 16 Ohms removeBMS BMS5C150LH 5 C 150 LH - 5" Ferrit Coaxial Speaker 130 W + 25 W 8/16 Ohms removeBMS BMS5C150L 5 C 150 L - 5" Ferrit Coaxial Speaker 130 W + 25 W 8 Ohms removeFaital Pro FP5FE120A Speaker FE Series 5'' 8 Ohm 80W remove
    NamePeerless 850 571 Mid Woofer 4" Hi - Fi CSC LINE (Pair) removeJBL 2106H 339485-001X Midrange Driver 2106HPL removeBMS BMS5C150H 5 C 150 H - 5" Ferrit Coaxial Speaker 130 W + 25 W 16 Ohms removeBMS BMS5C150LH 5 C 150 LH - 5" Ferrit Coaxial Speaker 130 W + 25 W 8/16 Ohms removeBMS BMS5C150L 5 C 150 L - 5" Ferrit Coaxial Speaker 130 W + 25 W 8 Ohms removeFaital Pro FP5FE120A Speaker FE Series 5'' 8 Ohm 80W remove
    ImagePeerless 850 571 Mid Woofer 4" Hi - Fi CSC LINE (Pair)JBL 2106H 339485-001X Midrange Driver 2106HPLBMS BMS5C150H 5 C 150 H - 5" Ferrit Coaxial Speaker 130 W + 25 W 16 OhmsBMS BMS5C150LH 5 C 150 LH - 5" Ferrit Coaxial Speaker 130 W + 25 W 8/16 OhmsBMS BMS5C150L 5 C 150 L - 5" Ferrit Coaxial Speaker 130 W + 25 W 8 OhmsFaital Pro FP5FE120A Speaker FE Series 5'' 8 Ohm 80W
    SKU850571339485-001BMS5C150HBMS5C150LHBMS5C150LFP5FE120A
    Rating
    Price Original price was: €135.00.Current price is: €111.37. incl. GR VAT Original price was: €210.80.Current price is: €199.21. incl. GR VAT Original price was: €324.60.Current price is: €275.91. incl. GR VAT Original price was: €327.36.Current price is: €278.25. incl. GR VAT Original price was: €324.60.Current price is: €275.91. incl. GR VAT€41.06 incl. GR VAT
    Stock

    Available on backorder

    Available on backorder

    Available on backorder

    Available on backorder

    Available on backorder

    Available on backorder

    AvailabilityAvailable on backorderAvailable on backorderAvailable on backorderAvailable on backorderAvailable on backorderAvailable on backorder
    Add to cart

    Add to cart

    Add to cart

    Add to cart

    Add to cart

    Add to cart

    Add to cart

    Description
    Content

    Specifications Power (RMS): 110 Watt Impadence :
    4 Ohm Megaphone Depth: 57mm Hole Diameter :
    100 mm Sensitivity :
    90 db Size :
    4 Inches

    		Genuine JBL 2106H, 2106HPL Midrange Driver #339485-001X used in VerTec Series VT4888 & VT4888DP-AN/CN/DA.
    • 90 dB sensitivity 1 W 11m
    • 130 W + 25 W Power handling
    • 1.5" + 1" voice coil
    • Single point source providing coherent wave front
    • 900 conical dispersion
    • Optimal for compact 2-way systems
    • 90 dB sensitivity 1 W 11m
    • 130 W + 25 W Power handling
    • 1.5" + 1" voice coil
    • Single point source providing coherent wave front
    • 900 conical dispersion
    • Optimal for compact 2-way systems
    • 90 dB sensitivity 1 W 11m
    • 130 W + 25 W Power handling
    • 1.5" + 1" voice coil
    • Single point source providing coherent wave front
    • 900 conical dispersion
    • Optimal for compact 2-way systems

    Product type Loudspeaker Chassis

    Type PA
    Nominal Diameter 5 "
    Nominal Diameter 130 mm
    Voice Coil 1.26 "
    Voice Coil 32 mm
    Overall diameter 124.6 mm
    Pitch Circle Diameter 133 mm
    Section Diameter 114 mm
    Mounting holes 4
    Diameter of fixing holes 6 mm
    Depth 65 mm
    Nominal Impedance 8 Ohm(s)
    Nominal Load Capacity 80 W
    maximum rated load 160 W
    Sensitivity (1 W / 1 m) 88 dB
    Frequency response 63 - 6300 Hz
    Voice Coil Material copper
    Magnet Ferrite
    Depth of the magnetic gap 6 mm
    Thiele & Small Parameter
    Fs (Resonance Frequency) 65 Hz
    Re (DC resistance) 5.4 Ohm(s)
    Qms (mechanical quality) 7.35
    Le (inductance of the voice coil) 0.41 mH
    Qes (electrical quality) 0.46
    Qts (overall quality) 0.43
    Vas (equivalent volume) 5.16
    Mms (moving mass) 11 g
    BL (power factor) 6.9 T/m
    Xmax (maximum displacement) 5.25 mm
    Cms (elasticity of the suspension) 0.55 mm/N
    Sd (membrane area) 79.8 cm²
    Rms (mechanical loss resistance) 0.7 kg/s
    Weight 1,12 kg
    Weight0.40 kg3.00 kg1.80 kg1.80 kg1.80 kg10.20 kg
    DimensionsN/AN/AN/AN/AN/AN/A
    Additional information
    Weight 0.40 kg
    Speaker Inch

    Weight 3.00 kg
    Weight 1.80 kg
    Speaker Inch

    Weight 1.80 kg
    Speaker Inch

    Weight 1.80 kg
    Speaker Inch

    Weight 10.20 kg
    Speaker Inch
