HK Audio RS 82 Powerworks Compact 2-Way Speaker 250 Watts

• 37 Hz to 18 kHz frequency range (-10 dB)
• 150W pink noise, 300 watts continuous program power capacity
• 110 x 85 degree coverage with rotatable horn
• 115W, 55W, 28W at 70V/100V (plus 14W taps at 70V only)
• 8 Ohm Bypass
• Outdoor-rated screw down input terminal strip (with MTC-PC2 sealed entrance cover)
• Available in black or white (Control 29AV-WH)
• Dimensions (HxWxD): 518 mm x 305 mm x 280 mm (20.3 in x 12.0 in x 11.0 in)
• Net Weight: 12.2 kg (26.8 lb

The JBL Control 128W premium in-wall speaker designed for applications where top performance is required. The high performance 8 inch wooer features apolymer-coated aluminum cone with pure butyl rubber surround. The 1" pure titanium dome tweeter is mounted on a low-diffraction swivel-mounting system enabling the user to direct high frequencies where required without the diffraction distortion inherent in other aimable tweeter designs.

JBL Control 128W at a Glance:

• 30 Hz - 20 kHz frequency range.

• 120W continuous program (60W cont. pink, 240W cont. peak).

• 90 dB sensitivity (1W/1m).

• High-slope crossover network produces natural sound and even coverage.

• Optional MTC-128RIF Rough-In-Frame for new construction installation to wallstuds.

The D 8 is a light-weight, robust 8“/1”, 2-way plastic cabinet for professional sound reinforcement applications. With a variety of suspension accessories and conservative cosmetics, the D 8 is ideally suited to be used in demanding fixed installations.
The cabinet is manufactured from ABS and therefore is extremely resistant against abuse on the road. For low and mid frequencies a DYNACORD DND8200-8 neodymium transducer is used. The Electro-Voice DH3 driver is used for the projection of the high frequencies. The Constant-Directivity HF horn has been integrated into the baffle by CAD methods. The nominal coverage angle of the cabinet is 90°*90°, horizontal*vertical, respectively.
Power handling of the cabinet is 250 W (rated) and 1000W (peak). The maximum sound pressure level is 124 dB, the frequency range of the D 8 is from 65Hz to 20kHz. The D 8 is ideally suited for applications as full-range cabinet or as Mid-Hi cabinet in high-performance small-format active and passive satellite systems.
Every transducer is protected against short-term thermal overload with thermal cutout switches and halogen protectors. In case of a potential thermal overload the power applied to the speakers is reduced to a safe level. The protection exhibits ʽsoftʼ switching characteristics, so no annoying clicks or pops are audible. The circuitry automatically resets after the voice coil temperature has reached a safe value.
Extremely durable acoustic foam mounted to a strong powder-coated steel grille protects the loudspeaker components against any mechanical damage. The trapezoidally shaped enclosure also allows employing the cabinet in monitoring applications. A stable, integrated carrying handle and the integrated stand socket for pole-mount stands allow easy transportation and set-up. A protective cover is available as an optional accessory.

F-2000 Series indoor speaker designed to provide high quality sound and reliable performance for restaurants, retail and audio/visual applications. Features include two-way bass-reflex design, high impact polystyrene enclosure with an 8" low frequency driver and dome tweeter. For challenging acoustic environments, users can easily reduce the high frequency dispersion of F-2000 models by simply installing an included horn adapter. White, 8 ohm.

Features:

• Compact box speakers for music and voice paging distribution
• Excellent sound quality
• Octagonal horn design for smooth coverage
• Adjustable high frequency dispersion
• Extruded cabinet design improves low frequency performance
• Individual protection circuit on each component
• Paintable grille and enclosure
• Wall/ceiling-mount bracket included
• Optional board, cluster and pole-mount brackets
• OmniMount-compatible (Series 20.5CA/WA)
• Optional subwoofers, model HB-1, FB-100 or FB-120
• Five year warranty

Specifications:

• LF Driver: 8” cone woofer
• HF Driver: 1” hard-dome tweeter
• Crossover: 2.5kHz
• Power Handling: 180W (cont. PGM), 60W (pink noise), 60W (70V transformer version)
• Sensitivity (1W, 1m): 93dB SPL
• Dispersion (adjustable):
  110° H x 100 ° V
  80° H x 80° V

Powerful monitor-speaker

• Active speaker-system for direct connection with the signal source
• 2-way speaker-system
• Clear and powerful sound
• 2-band EQ master-signal and master-signal
• Wide range of uses in spite of minimum size
• Ideal for decentral sound-surroundings, e.g. in bistros, restaurants, bars or studio
• Delivery includes mounting bracket for ceiling or wall installation

Technical Information:
