PEERLESS D19TD05-08 Dome Tweeter , 8 ohm, 19 mm Voice Coil, Front Plate 3.7 inch Diameter

D19TD PEERLESS
PEERLESS
peerless D19TD05-tweeter
All products by PEERLESS

€25.00 incl. GR VAT

Only 2 left in stock (can be backordered)

EAN: N/A
Installments calculation €
CompareAdd to wishlist Submit Better Price

    Availability: Available Available SKU: D19TD05-08 Category: Brand:
    Nominal impedance 8 ohm
    Dimensional category 3.5 inch
    Manufacturer sensitivity 87.5 dB
    Nominal power handling 50 W
    Nominal impedance 8 ohm
    Dimensional category 3.5 inch
    Manufacturer sensitivity 87.5 dB
    Nominal power handling 50 W



    Read more

    This D family tweeter features an 8ohm 19mm voice coil, a treated fabric dome, with a ferrite magnet and a ABS faceplate, and ferrofluid in the gap of the ferrite magnet motor, providing enhanced cooling of the voice coil. Is designed to be a high performance transducer.

    Features

    • Ferrite Magnet
    • Silk Diaphragm
    • Silk Surround
    • Ferrofluid Filled Motor
    • Faceplate
    Transducer Size 25 mm
    Impedance 8 Ω
    Resonance Frequency 1900 Hz
    Sensitivity @ 1W/1m 91.3 dB
    Rated Noise Power 50 W
    Frequency Range 2500 – 20000 Hz
    Net Weight 0.272 kg
    Weight 0.5 kg

    Reviews

    There are no reviews yet.

    Be the first to review “PEERLESS D19TD05-08 Dome Tweeter , 8 ohm, 19 mm Voice Coil, Front Plate 3.7 inch Diameter”

    Your email address will not be published. Required fields are marked *

    Quick Comparison

    PEERLESS D19TD05-08 Dome Tweeter , 8 ohm, 19 mm Voice Coil, Front Plate 3.7 inch Diameter removeCIARE Compression tweeter CT440 8 ohm 1.25" 110dB 250W removePeerless DX20BF00-04, 4 ohm Dome tweeter 60W removeJBL HF CONTROL 23 Replacement Tweeter removeJBL 01830 TWEETER CONTROL 10 removeKRK TWTK00024 TWEETER FOR KRK series RP remove
    NamePEERLESS D19TD05-08 Dome Tweeter , 8 ohm, 19 mm Voice Coil, Front Plate 3.7 inch Diameter removeCIARE Compression tweeter CT440 8 ohm 1.25" 110dB 250W removePeerless DX20BF00-04, 4 ohm Dome tweeter 60W removeJBL HF CONTROL 23 Replacement Tweeter removeJBL 01830 TWEETER CONTROL 10 removeKRK TWTK00024 TWEETER FOR KRK series RP remove
    ImageD19TD PEERLESSciare ct440 neodymium horn tweeter 110dbPeerless DX20BF00-04, 4 ohm Dome tweeter 60WJBL HF CONTROL 23 Replacement TweeterJBL 01830 TWEETER CONTROL 10KRK TWTK00024 TWEETER FOR KRK series RP
    SKUD19TD05-08CT440-8DX20BF00-04JBL-123-00000-00TWEETERCONTROL10TWTK00024
    Rating
    Price€25.00 incl. GR VAT Original price was: €200.87.Current price is: €156.43. incl. GR VAT Original price was: €36.00.Current price is: €29.00. incl. GR VAT€54.99 incl. GR VAT Original price was: €194.68.Current price is: €192.71. incl. GR VAT€60.49 incl. GR VAT
    Stock

    Only 2 left in stock (can be backordered)

    Available on backorder

    Only 2 left in stock (can be backordered)

    Only 2 left in stock

    Available on backorder

    Only 1 left in stock (can be backordered)

    AvailabilityOnly 2 left in stock (can be backordered)Available on backorderOnly 2 left in stock (can be backordered)Only 2 left in stockAvailable on backorderOnly 1 left in stock (can be backordered)
    Add to cart

    Add to cart

    Add to cart

    Add to cart

    Add to cart

    Add to cart

    Add to cart

    Description
    Nominal impedance 8 ohm
    Dimensional category 3.5 inch
    Manufacturer sensitivity 87.5 dB
    Nominal power handling 50 W
    		Compression tweeter Ciare CT440, 8 ohm, 1.25 inch
    ContentThis D family tweeter features an 8ohm 19mm voice coil, a treated fabric dome, with a ferrite magnet and a ABS faceplate, and ferrofluid in the gap of the ferrite magnet motor, providing enhanced cooling of the voice coil. Is designed to be a high performance transducer.

    Features

    • Ferrite Magnet
    • Silk Diaphragm
    • Silk Surround
    • Ferrofluid Filled Motor
    • Faceplate
    Transducer Size 25 mm
    Impedance 8 Ω
    Resonance Frequency 1900 Hz
    Sensitivity @ 1W/1m 91.3 dB
    Rated Noise Power 50 W
    Frequency Range 2500 - 20000 Hz
    Net Weight 0.272 kg
    The Ciare CT440 1.25" Neodymium Horn Tweeter is a high-quality driver designed to deliver exceptional high-frequency response and clarity. Featuring a 1.25-inch diaphragm and a neodymium magnet, this tweeter provides an impressive frequency response of 1.5kHz-18kHz, ensuring clear and accurate sound reproduction across the entire high-frequency spectrum.
    Key Features
    • Stylish black-chrome design fits into most decor
    • Ultra-high 110 dB sensitivity to keep up with the most demanding SPL systems
    • Broad 1,000 to 18,000 Hz response

    General
    Product type Compression tweeter
    Brand Ciare
    Reference CT440

    Informations
    Nominal impedance 8 ohm
    Dimensional category 4.5 inch
    Manufacturer sensitivity 110 dB
    Nominal power handling 250 W
    Max power handling 500 W
    Bandwidth 2000÷20000 Hz
    Recommended min cutoff frequency 2800 Hz

    Fundamental parameters
    Re 4.5 ohm

    Small signal parameters
    Fs 1400 Hz

    Data
    Weight ~0.8 kg

    Dimensions
    Voice coil diameter 1.75 inch
    External dimensions 112 | 112 mm
    Baffle cutout diameter 95 mm
    Depth 68 mm
    Front thickness 4 mm
    Depth after front 64 mm
    Diamètre aimant (mm) 78 mm

    Shape & Materials
    Front chape Non cylindrical
    Magnet type Neodymium
    Winding material Aluminium
    Dome material Mylar
    Nominal impedance, (Zn)
    4 Ohm
    DC resistance, (Re)
    2.81 Ohm
    Voice coil inductance, (Le)
    0.01 mH
    Effective piston area, (Sd)
    4.9 cm2
    Voice coil diameter
    19.3 mm
    Air gap height
    2 mm
    Linear coil travel
    0.2 mm
    Diaphragm material
    Fabric
    Rated power
    60 W
    Net weight
    0.17 kg
    Free air resonance, (Fs)
    822 Hz
    Sensitivity, (2.83V/1m)
    90.1 dB
    Mechanical Q-factor, (Qms)
    2.24
    Electrical Q-factor, (Qes)
    2.93
    Total Q-factor, (Qts)
    1.27
    Moving mass incl. air, (Mms)
    0.2 g
    Force factor, (Bl)
    1 T*m
    Equivalent volume, (Vas)
    0.0 L
    Compliance, (Cms)
    184.5 um/N
    Ratio BL/√Re
    0.59 N/√W
    Ratio Fs/Qts
    647 Hz
    The THD measurements at distance of 315 mm and voltage levels 2.83 - 8 Volt were carried out with High Pass Filter "on" (2nd order Butterworth type, 800 Hz cutoff, HPF2-800)​
    		JBL Control 23, Original Speaker Tweeter Part # 123-00000-00
    • JBL Control 23 Original Tweeter Part # 123-00000-00
    • This is a complete brand new JBL, Control 23 tweeter
    • Voice coil: 1/2" (13mm)
    • Diameter: 2-3/4" x 1-7/8“ (70mm x 48mm)
    • Impedance: 8 ohm, DCR: 6.7 ohm
    • Titanium deposit dome with copper voice coil on Kapton former
    • Fits JBL Driver and Cabinet Models:JBL: Control 23, 123-00000-00, 1230000000

    JBL PRO-3 01830 TWEETER CONTROL 10

    		KRK TWTK00024 / TWK7 TWEETER FOR KRK series RP Replacement KRK tweeter for the KRK RP G2 active speaker. This genuine KRK tweeter is used throughout the Rokit series G1 and G2 active speaker range. It is suitable for use in the following models:
    • RP5
    • RP5 G2
    • RP6
    • RP6 G2
    • RP8
    • RP8 G2
    Weight0.5 kg1 kg0.5 kg0.10 kg0.30 kg1.00 kg
    DimensionsN/AN/AN/AN/AN/AN/A
    Additional information
    Weight 0.5 kg
    Weight 1 kg
    Weight 0.5 kg
    Weight 0.10 kg
    Weight 0.30 kg
    Weight 1.00 kg
